Auto-Instrumenting NestJS Apps with OpenTelemetry

In this tutorial, we will go through a working example of a NestJS application auto-instrumented with OpenTelemetry.

In our example we will use a simple application that outputs “Hello World!” when we call it in the browser.

We will instrument this application with OpenTelemetry’s Node.js client library to generate trace data and send it to an OpenTelemetry Collector. The Collector will then export the trace data to an external distributed tracing analytics tool of our choice.

OpenTelemetry structure. Source: OpenTelemetry Guide

If you are new to the OpenTelemetry open source project, or if you are looking for more application instrumentation options, check out this guide.

Create the Example Application

First of all, we need the Nest CLI to initialize and run Nest applications. We are going to install it by running:

$ npm install -g @nestjs/cli

Now we need to can create a new Nest project by running:

$ npm i -g @nestjs/cli
$ nest new project-name

Once the installation has been completed, we can run the application using the command:

$ npm run start

Now, when we access http://localhost:3000/ we can see Hello World! Output in the browser.

Now that we’ve got the example application working, let’s take it down, and go through the steps for adding tracing to it with OpenTelemetry, then we’ll run the instrumented app and see the tracing in our Jaeger UI.

Step 1: Install OpenTelemetry Packages

In our next step, we will need to install all OpenTelemetry modules that are required to auto-instrument our app:

opentelemetry/api
opentelemetry/instrumentation
opentelemetry/tracing
opentelemetry/exporter-trace-otlp-http
opentelemetry/resources
opentelemetry/semantic-conventions
opentelemetry/auto-instrumentations-node
opentelemetry/sdk-node

To install these packages, we run the following command from our application directory:

npm install --save @opentelemetry/api
npm install --save @opentelemetry/instrumentation
npm install --save @opentelemetry/tracing
npm install --save @opentelemetry/exporter-trace-otlp-http
npm install --save @opentelemetry/resources
npm install --save @opentelemetry/semantic-conventions
npm install --save @opentelemetry/auto-instrumentations-node
npm install --save @opentelemetry/sdk-node

These packages provide good automatic instrumentation of our web requests across express, http and the other standard library modules used. Thanks to this auto-instrumentation, we don’t need to change anything in our application code apart from adding a tracer. We will do this in our next step.

Step 2: Add a tracer to the NestJS application

A Node.js SDK tracer is the key component of NestJS instrumentation. It takes care of the tracing setup and graceful shutdown. The repository of our example application already includes this module. If you would create it from scratch, you will just need to create a file called tracing.js with the following code:

"use strict";

const {
    BasicTracerProvider,
    ConsoleSpanExporter,
    SimpleSpanProcessor,
} = require("@opentelemetry/tracing");
const { OTLPTraceExporter } = require("@opentelemetry/exporter-trace-otlp-http");
const { Resource } = require("@opentelemetry/resources");
const {
    SemanticResourceAttributes,
} = require("@opentelemetry/semantic-conventions");

const opentelemetry = require("@opentelemetry/sdk-node");
const {
    getNodeAutoInstrumentations,
} = require("@opentelemetry/auto-instrumentations-node");


const exporter = new OTLPTraceExporter({
    url: "http://localhost:4318/v1/traces"
});

const provider = new BasicTracerProvider({
    resource: new Resource({
        [SemanticResourceAttributes.SERVICE_NAME]:
            "YOUR-SERVICE-NAME",
    }),
});
// export spans to console (useful for debugging)
provider.addSpanProcessor(new SimpleSpanProcessor(new ConsoleSpanExporter()));
// export spans to opentelemetry collector
provider.addSpanProcessor(new SimpleSpanProcessor(exporter));

provider.register();
const sdk = new opentelemetry.NodeSDK({
    traceExporter: exporter,
    instrumentations: [getNodeAutoInstrumentations()],
});

sdk
    .start()
    .then(() => {
        console.log("Tracing initialized");
    })
    .catch((error) => console.log("Error initializing tracing", error));

process.on("SIGTERM", () => {
    sdk
        .shutdown()
        .then(() => console.log("Tracing terminated"))
        .catch((error) => console.log("Error terminating tracing", error))
        .finally(() => process.exit(0));
});

In our example, we are going to keep this file in the same directory as the application code.

As you can see, the tracing.js takes care of instantiating the trace provider and configuring it with a trace exporter of our choice. As we’d like to send the trace data to an OpenTelemetry Collector (as we’ll see in the following steps), we use the CollectorTraceExporter.

In the async function boostrap section of the application code we are going to initialize the tracer as follows:

import { NestFactory } from '@nestjs/core';
import { AppModule } from './app.module';

async function bootstrap() {
 require('./tracing.js')
 const app = await NestFactory.create(AppModule);
 await app.listen(3000);
}
bootstrap();

If you want to see some trace output on the console to verify the instrumentation, you can use the ConsoleSpanExporter that will print to the console. The above tracer.js already has the ConsoleSpanExporter configured for you.

This is the only coding you need to do to instrument your Node.js app. In particular, you don’t need to make any code changes to the service modules themselves – they will be auto-instrumented for you.

Step 3: Set Up OpenTelemetry Collector to Collect and Export Traces to our Backend

The last component that we will need is the OpenTelemetry Collector, which we can download here

In our example, we will be using the otelcontribcol_darwin_amd64 flavor, but you can choose any other version of the collector from the list, as long as the collector is compatible with your operating system.

The data collection and export settings in the OpenTelemetry Collector are defined by a YAML config file. We will create this file in the same directory as the collector file that we have just downloaded and call it config.yaml. This file will have the following configuration:

receivers:
  otlp:
    protocols:
      grpc:
      http:

exporters:
  logzio:
    account_token: "<<TRACING-SHIPPING-TOKEN>>"
    #region: "<<LOGZIO_ACCOUNT_REGION_CODE>>" - (Optional)

processors:
  batch:

extensions:
  pprof:
    endpoint: :1777
  zpages:
    endpoint: :55679
  health_check:

service:
  extensions: [health_check, pprof, zpages]
  pipelines:
    traces:
      receivers: [otlp]
      processors: [batch]
      exporters: [logzio]

In this example, we will send the traces to Logz.io’s Distributed Tracing service. So, we will configure the collector with the Logz.io exporter, which will send traces to the Logz.io account defined by the account token (if you don’t have an account, you can get a free one here). However, you can also export the trace data from the OpenTelemetry Collector to any other tracing backend by adding the required exporter configuration to this file (you can read more on exporters options here).

Step 4: Run it All Together and Verify in Jaeger UI

Now that we have everything set up, let’s launch our system again and send some traces.

First, we need to start the OpenTelemetry Collector. We do this by specifying the path to the collector and the required config.yaml file. In our example, we run both files from application directory as follows:

./otelcontribcol_darwin_amd64 --config ./config.yaml

The collector is now running and listening to incoming traces on port 4318 (HTTP traffic).

Our next step is to start the application by running the following command from the application directory:

npm run start

All that is left for us to do at this point is to visit  http://localhost:3000/ so we have sample data to look at. The Collector will then pick up data and send it to the distributed tracing backend defined by the exporter in the collector config file. In addition, our tracer exports the traces to the console so we can see what is being generated and sent.

The sample trace visualization on Jaeger UI’s Trace Timeline view

Summary

As you can see, OpenTelemetry makes it pretty simple to automatically instrument NestJS applications. All we had to do, was:

  • Install required Node.js packages for OpenTelemetry instrumentation
  • Add a traceing.js to the application
  • Deploy and configure OpenTelemetry Collector to receive the trace data and send it to our tracing analytics backend
  • Re-run the instrumented application and explore the traces arriving to the tracing analytics backend with Jaeger UI

For more information on OpenTelemetry instrumentation, visit this guide. If you are interested in trying this integration out using Logz.io backend, feel free to sign up for a free account and then follow this documentation to set up auto-instrumentation for your own NestJS application.
